2 Core Enhanced Fire-Survival Screened LSZH Cable
KEY FEATURES
- Colour-coded multicore fire-life construction
- Overall screened LSZH family baseline
- Enhanced fire-survival architecture — certification evidence required before claim
- Red / White controlled Series rows
- 305 m standard TMT package
Chat with Sales
0
People watching this product now!
Description
Choosing the 2 Core Enhanced Fire-Survival Screened LSZH Cable
Two cores carry one circuit that must keep working during a fire, such as alarm sounders, voice alarm speakers or emergency signalling.
Related options in this range: 3 Core Enhanced Fire-Survival Screened LSZH Cable · 3 Core Standard Fire-Survival Screened LSZH Cable · 4 Core Enhanced Fire-Survival Screened LSZH Cable · 4 Core Standard Fire-Survival Screened LSZH Cable
Order code: 02C-S-FE. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT 2 Core Enhanced Fire-Survival Screened LSZH Cable Series
2-core enhanced fire-resistant screened LSZH cable family for installations requiring a higher circuit-integrity classification, subject to exact BS 7629-1 / fire-test evidence.
KEY FEATURES
- Colour-coded multicore fire-life construction
- Overall screened LSZH family baseline
- Enhanced fire-survival architecture — certification evidence required before claim
- Red / White controlled Series rows
- 305 m standard TMT package
TYPICAL APPLICATIONS
- Enhanced fire-alarm circuits
- Emergency lighting in complex / phased-evacuation projects
- Voice-alarm / life-safety systems where specified
- High-rise and critical building routes
- Extended circuit-integrity applications
Technical Specification
| TECHNICAL SPECIFICATION | VALUE |
| Product family | 2 Core Enhanced Fire-Survival Screened LSZH Cable |
| Series | 02C-S-FE |
| Primary application | Fire alarm, emergency lighting and life-safety control circuits |
| Core / geometry | 2 conductors |
| Conductor material | Bare copper |
| AWG | 16 / 14 / 12 AWG |
| Screening | Overall foil screen + drain / CPC |
| Outer sheath | LSZH • Red / White |
| Rated voltage class | 300/500 V class |
| Fire-survival level | Enhanced |
| Standard package | 305 m |
AWG / SERIES AVAILABILITY
| AWG | SERIES AVAILABILITY |
| 16 AWG | 02C-S-FE Series • Red / White |
| 14 AWG | 02C-S-FE Series • Red / White |
| 12 AWG | 02C-S-FE Series • Red / White |
Additional information
| AWG | 12 awg, 14 awg, 16 awg |
|---|---|
| Brand | TMT Global |
| Colour | Red, White |
| Jacket Type | LSZH |
| Length | 305 m |
Download
Ordering Notes
Dear Customer For Updated Prices and Specifications Contact Sales Team.
Tel: 0138053166
Mob: 0552792350
Email: info@sahilcommunication.sa
Web: www.sahilcommunication.sa
Short Address: EKDA6556
Building No: 6556
Street: prince bader ibn abdul aziz
Secondary No: 2723
Distract: Al Khobar Ash Shamaliyah
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 16 awg | LSZH | Red | 305 m |  | |
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 16 awg | LSZH | White | 305 m | | |
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 14 awg | LSZH | Red | 305 m | | |
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 14 awg | LSZH | White | 305 m | | |
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 12 awg | LSZH | Red | 305 m | | |
| 2 Core Enhanced Fire-Survival Screened LSZH Cable | 02C-S-FE | 12 awg | LSZH | White | 305 m | |
