TMT Global 4 Core Foil Shielded PA Control Cable product image showing the cable coil and exposed conductor cutaway.

4 Core Foil-Shielded PA / Control Cable

KEY FEATURES

  • Four stranded bare-copper conductors
  • Overall aluminium/polyester foil screen
  • Drain wire for screen termination
  • PVC, LSZH and outdoor PE options
  • Exact AWG and jacket ordering rows
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
SKU: 04C-S-PA Category:
Description

TMT Global 4 Core Foil-Shielded PA / Control Cable Series

TMT Global 4 Core Foil-Shielded PA / Control Cable is a versatile public-address and commercial-audio family for paired audio/control conductors, zone-control wiring and intercom circuits. The overall foil screen supports installations near lighting, power and building-service wiring.

KEY FEATURES

  • Four stranded bare-copper conductors
  • Overall aluminium/polyester foil screen
  • Drain wire for screen termination
  • PVC, LSZH and outdoor PE options
  • Exact AWG and jacket ordering rows

TYPICAL APPLICATIONS

  • PA zone-control wiring
  • Intercom and paging systems
  • Commercial-audio control circuits
  • Sound-system interfaces
  • Building communication systems

Technical Specification

PARAMETER SPECIFICATION
Product type Screened PA / control bulk cable
Geometry / configuration 4 core
Conductor material Bare copper
Conductor construction Stranded copper conductors
Available conductor sizes 14 AWG / 16 AWG / 18 AWG / 20 AWG / 22 AWG
Conductor identification Colour-coded insulated conductors
Core / pair construction 4 colour-coded insulated conductors
Screening Overall foil screen
Drain wire Drain wire included
Outer-jacket options PVC / LSZH / PE Outdoor
Cable form Round
Standard colours Grey (PVC/LSZH) / Black (PE Outdoor)
Package length 305 m standard package
Typical applications PA audio, zone control, intercom and auxiliary system circuits

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA SERIES AVAILABILITY
14 AWG 2.08 mm² PVC / LSZH / PE Outdoor • 305 m
16 AWG 1.31 mm² PVC / LSZH / PE Outdoor • 305 m
18 AWG 0.823 mm² PVC / LSZH / PE Outdoor • 305 m
20 AWG 0.519 mm² PVC / LSZH / PE Outdoor • 305 m
22 AWG 0.326 mm² PVC / LSZH / PE Outdoor • 305 m
Additional information
ColourBlack, Grey
Jacket TypePVC, LSZH, PE Outdoor
Length305 m
BrandTMT Global
AWG14 awg, 16 awg, 18 awg, 20 awg, 22 awg
Download

visit: www.tmtglobal.co.uk

tmt global ul
tmt-global-BASEC
tmt global INTERTEK
tmt global IEC
tmt global ISO-9001
sira approved brand tmt global
tmt global ROHSS
tmt-global-ETISALAT
du approved brand tmt global
tmt global CE
tmt global FCC
ICC
Ordering Notes
Dear Customer For Updated Prices and Specifications Contact Sales Team. Tel: 0138053166 Mob: 0552792350 Email: info@sahilcommunication.sa Web: www.sahilcommunication.sa Short Address: EKDA6556 Building No: 6556 Street: prince bader ibn abdul aziz Secondary No: 2723 Distract: Al Khobar Ash Shamaliyah
Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourPackQR Code
4 Core Foil-Shielded PA / Control Cable04C-S-PA14 awgPVCGrey305 m QR code for 0414BPSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA14 awgLSZHGrey305 m QR code for 0414BLSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA14 awgPE OutdoorBlack305 m QR code for 0414BKSRK-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA16 awgPVCGrey305 m QR code for 0416BPSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA16 awgLSZHGrey305 m QR code for 0416BLSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA16 awgPE OutdoorBlack305 m QR code for 0416BKSRK-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA18 awgPVCGrey305 m QR code for 0418BPSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA18 awgLSZHGrey305 m QR code for 0418BLSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA18 awgPE OutdoorBlack305 m QR code for 0418BKSRK-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA20 awgPVCGrey305 m QR code for 0420BPSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA20 awgLSZHGrey305 m QR code for 0420BLSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA20 awgPE OutdoorBlack305 m QR code for 0420BKSRK-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA22 awgPVCGrey305 m QR code for 0422BPSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA22 awgLSZHGrey305 m QR code for 0422BLSRG-PA
4 Core Foil-Shielded PA / Control Cable04C-S-PA22 awgPE OutdoorBlack305 m QR code for 0422BKSRK-PA
