TMT Global 2-Wire Bus + 2 Core Power Composite Intercom Cable, with one twisted foil-shielded two-wire data pair plus two separate insulated power conductors and four copper tips.

2-Wire Bus + 2 Core Power Composite Intercom Cable

KEY FEATURES

  • 2 bus + 2 power
  • Bus unshielded; power separate
  • PVC / LSZH / PE Outdoor
  • 305 m standard package
  • Factory evidence required for system/electrical claims
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
Category:
Description

TMT 2-Wire Bus + 2 Core Power Composite Intercom Cable Series

TMT Global 2-Wire Bus + 2 Core Power Composite Intercom Cable is a controlled Security & ELV cable family for professional door-entry and intercom installations. Mixed-gauge intercom composite carrying a two-wire communication bus together with a separate two-core power section under one sheath. Mixed conductor schedules remain exact Series rows under one physical composite family. Exact released size/schedule and jacket variations remain searchable Series rows under this product page.

KEY FEATURES

  • 2 bus + 2 power
  • Bus unshielded; power separate
  • PVC / LSZH / PE Outdoor
  • 305 m standard package
  • Factory evidence required for system/electrical claims

APPLICATIONS

  • Door station + local power
  • Longer door-entry runs
  • Single-pull intercom installation

Technical Specification

SPECIFICATION VALUE
Product family 2-Wire Bus + 2 Core Power Composite Intercom Cable
Series 04M-IP
Primary application Bus + local power
Physical geometry 2 bus + 2 power
Conductor size / schedule 2C20 bus + 2C16 power; 2C22 bus + 2C18 power
Conductor material Bare copper
Screening Bus unshielded; power separate
Outer-jacket options PVC / LSZH / PE Outdoor
Standard colours White for PVC/LSZH; Black for PE Outdoor
Standard package 305 m
Product format Fixed mixed-gauge intercom bus + power composite
Series configuration Approved conductor schedule and jacket combinations shown below

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA (mm²) SERIES AVAILABILITY
18 AWG 0.823 PVC / LSZH / PE Outdoor
20 AWG 0.518 PVC / LSZH / PE Outdoor
22 AWG 0.326 PVC / LSZH / PE Outdoor
Download

visit: www.tmtglobal.co.uk

tmt global ul
tmt-global-BASEC
tmt global INTERTEK
tmt global IEC
tmt global ISO-9001
sira approved brand tmt global
tmt global ROHSS
tmt-global-ETISALAT
du approved brand tmt global
tmt global CE
tmt global FCC
ICC
Ordering Notes
Dear Customer For Updated Prices and Specifications Contact Sales Team. Tel: 0138053166 Mob: 0552792350 Email: info@sahilcommunication.sa Web: www.sahilcommunication.sa Short Address: EKDA6556 Building No: 6556 Street: prince bader ibn abdul aziz Secondary No: 2723 Distract: Al Khobar Ash Shamaliyah
