TMT Global 16-Core Separable Peel Legacy Access Control Composite, black composite cable with distinct peel-apart subcables for legacy reader and lock power, foil-screened reader bundle, exactly sixteen insulated copper conductors with sixteen visible tips.

16 Core Separable Peel Legacy Access Control Composite

KEY FEATURES

  • Access-control-specific construction
  • 3PR22 + 2C22 + 4C22 + 4C18
  • Reader pair(s) shielded
  • 305 m standard package
  • Factory evidence required for released electrical values
Chat with Sales
View / Print DatasheetContact Sales
0 People watching this product now!
SKU: ACC-PEEL-ACBP Category:
Description

TMT 16 Core Separable Peel Legacy Access Control Composite Series

TMT Global 16 Core Separable Peel Legacy Access Control Composite is a controlled Security & ELV cable family for professional door access-control installations. Separable peel-style access-control composite in which the application subcables are joined for a single pull and then split at the door/controller end. This is a distinct physical form from common-jacket composite cable. Jacket and permitted conductor-size variations remain exact searchable Series rows under this product page.

KEY FEATURES

  • Access-control-specific construction
  • 3PR22 + 2C22 + 4C22 + 4C18
  • Reader pair(s) shielded
  • 305 m standard package
  • Factory evidence required for released electrical values

APPLICATIONS

  • Single-pull door cabling
  • Fast field separation
  • Reader/contact/REX/lock

Technical Specifications

PARAMETER TECHNICAL SPECIFICATION
Product family 16 Core Separable Peel Legacy Access Control Composite
Series ACC-PEEL-ACBP
Primary function Separable legacy composite
Conductor schedule 3PR22 + 2C22 + 4C22 + 4C18
Conductor construction Stranded copper conductors
Screening Reader pair(s) shielded
Cable form Separable peel / application-coloured subcables
Jacket options PVC / LSZH
Standard colours Grey
Standard package 305 m
Installation / protocol Low-voltage access-control wiring
Series status PVC / LSZH: Core market

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG NOMINAL AREA (mm²) SERIES AVAILABILITY
18 AWG 0.823 PVC / LSZH
22 AWG 0.326 PVC / LSZH
Additional information
AWG22 awg
BrandTMT Global
ColourGrey
Jacket TypePVC, LSZH
Length305 m
Download

visit: www.tmtglobal.co.uk

tmt global ul
tmt-global-BASEC
tmt global INTERTEK
tmt global IEC
tmt global ISO-9001
sira approved brand tmt global
tmt global ROHSS
tmt-global-ETISALAT
du approved brand tmt global
tmt global CE
tmt global FCC
ICC
Ordering Notes
Dear Customer For Updated Prices and Specifications Contact Sales Team. Tel: 0138053166 Mob: 0552792350 Email: info@sahilcommunication.sa Web: www.sahilcommunication.sa Short Address: EKDA6556 Building No: 6556 Street: prince bader ibn abdul aziz Secondary No: 2723 Distract: Al Khobar Ash Shamaliyah
Ordering Information
Item NameItem Code / SKUSeriesAWG / mm²JacketColourPackQR Code
16 Core Separable Peel Legacy Access Control CompositeACC-PEEL-ACBP22 awgPVCGrey305 m QR code for 1622BPSEG-ACBP
16 Core Separable Peel Legacy Access Control CompositeACC-PEEL-ACBP22 awgLSZHGrey305 m QR code for 1622BLSEG-ACBP
